The document presents an overview of querying data in Amazon S3 using SQL with Amazon Athena, highlighting benefits of S3 as a durable and scalable data storage solution. It discusses strategies for optimizing data ingestion and querying through techniques like partitioning, compression, and utilizing columnar formats. Additionally, it emphasizes cost-effective practices for managing and querying data in AWS environments.
![© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
The Example Data
• NYC Taxi & Limousine Commission rides
• Data is generated by kinesis-taxi-stream-
producer available at [1]:
java -jar kinesis-taxi-stream-producer.jar
-speedup 400 -statisticsFrequency 10000
-stream nyctlc-ingestion –noWatermark
-region eu-central-1 -adaptTime ingestion
• ~2GB/h of raw data, 11 days, 487 GB total
[1] https://github.com/aws-samples/flink-stream-
processing-refarch](https://image.slidesharecdn.com/20181108queryperformance-181109133258/85/Analytics-Web-Day-Query-your-Data-in-S3-with-SQL-and-optimize-for-Cost-and-Performance-12-320.jpg)
![© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Populate Partitions if paths are known
Issue Statements with Amazon Athena:
ALTER TABLE mytable
ADD PARTITION
(year='2015',month='01',day='01')
LOCATION 's3://[...]/2015/01/01/'
Why? Easy for predictable paths. Can be prepopulated.](https://image.slidesharecdn.com/20181108queryperformance-181109133258/85/Analytics-Web-Day-Query-your-Data-in-S3-with-SQL-and-optimize-for-Cost-and-Performance-20-320.jpg)
![© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Schema Information
Row Count Total Byte Size Size in Bytes Value Count Encoding
Download and build [1].
$ java -jar parquet-tools.jar meta <parquetfile>
[1] https://github.com/apache/parquet-mr/](https://image.slidesharecdn.com/20181108queryperformance-181109133258/85/Analytics-Web-Day-Query-your-Data-in-S3-with-SQL-and-optimize-for-Cost-and-Performance-30-320.jpg)
![© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
parquet-tools dump: Encoding & Statistics
total_amount:
- DOUBLE SNAPPY DO:0 FPO:4155231 SZ:329324/338501/1.03
[more]... ST:[min: -76.8, max: 1121.3, num_nulls: 0]
dropoff_datetime:
- BINARY SNAPPY DO:0 FPO:3315979 SZ:839131/5540639/6.60
[more]... ST:[no stats for this column]
Use (unix epoch) or partition by timestamp for time series
data.](https://image.slidesharecdn.com/20181108queryperformance-181109133258/85/Analytics-Web-Day-Query-your-Data-in-S3-with-SQL-and-optimize-for-Cost-and-Performance-31-320.jpg)
![© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.
Analyzing ORC: orcdumpfile
Spin up a single node/ master EMR Cluster and use the
hive command:
hive --orcfiledump file://<absolutepath>/file.orc
[…]
Column 7: count: 210141 hasNull: false min: -
76.96324157714844 max: 0.0 sum: -
1.5329986951126099E7
Column 8: count: 210141 hasNull: false min:
2018-08-30T00:13:48.573Z max: 2018-08-
30T00:28:49.564Z sum: 5043384
[…]](https://image.slidesharecdn.com/20181108queryperformance-181109133258/85/Analytics-Web-Day-Query-your-Data-in-S3-with-SQL-and-optimize-for-Cost-and-Performance-32-320.jpg)
Analytics Web Day | Query your Data in S3 with SQL and optimize for Cost and Performance
- 1. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Steffen Grunwald, AWS Solutions Architect Analytics Web Day, 8. November 2018 Query your data in S3 with SQL and optimize for cost and performance
- 2. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. What you will learn from this Session • Benefits of raw Data in Amazon Simple Storage Service • Query on S3 with Amazon Athena • Optimize your Data Structure • Compression • Partitioning • Columnar Formats • Derive Views from raw Data for frequent Queries
- 3. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Example Application Architecture Amazon Kinesis Streams Amazon Kinesis Analytics Amazon Kinesis Streams AWS Lambda Amazon CloudWatch Amazon Kinesis Firehose Amazon QuickSight AWS Glue Amazon S3 Amazon Athena Instance
- 4. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Benefits of raw Data in Amazon Simple Storage Service (S3) • Highly durable and cost-effective object store • Limitlessly scalable • Pay for what you use - in GB per month • Decouple storage from compute • Widely supported API by many consumers • Well integrated into other AWS systems Use S3 as long term storage to answer yet unknown questions of tomorrow.
- 5. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Ingest Data with Amazon Kinesis Firehose • Stores stream of records as files in a bucket • Path: <Optional Prefix> + "YYYY/MM/DD/HH“ (Ingestion Time, UTC) • Optionally compress (GZIP, ZIP, Snappy) • Optionally store as columnar format (ORC, Parquet) • Optionally transform records with AWS Lambda Amazon Kinesis Firehose Amazon S3 Bucket
- 6. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Athena is an interactive query service that makes it easy to analyze data directly from Amazon S3 using Standard SQL
- 7. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Query Data Directly from Amazon S3 • No loading of data • Query data in its raw format • No ETL required • Stream data directly from Amazon S3
- 8. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Presto SQL • ANSI SQL compliant • Complex joins, nested queries & window functions • Complex data types (arrays, structs, maps) • Partitioning of data by any key • date, time, custom keys • Presto built-in functions
- 9. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Athena Supports Multiple Data Formats • Text files, e.g., CSV, raw logs • Apache Web Logs, TSV files • JSON (simple, nested) • Compressed files • Columnar formats such as Parquet & ORC • AVRO support
- 10. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Amazon Athena is Cost Effective • Pay per query • $5 per TB scanned from S3 • DDL Queries and failed queries are free
- 11. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Demo: Query files from Amazon Kinesis Firehose with Amazon Athena and AWS Glue
- 12. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. The Example Data • NYC Taxi & Limousine Commission rides • Data is generated by kinesis-taxi-stream- producer available at [1]: java -jar kinesis-taxi-stream-producer.jar -speedup 400 -statisticsFrequency 10000 -stream nyctlc-ingestion –noWatermark -region eu-central-1 -adaptTime ingestion • ~2GB/h of raw data, 11 days, 487 GB total [1] https://github.com/aws-samples/flink-stream- processing-refarch
- 13. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Test Setup: Ingesting Data with different Settings Amazon Kinesis Streams Amazon S3 Instance Firehose (gzip) Firehose (raw) Firehose (orc) Firehose (parquet) (max Amazon Kinesis Firehose buffering hints: 128MB & 900s)
- 14. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Photo by Glen Noble on Unsplash
- 15. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Photo by Tang Junwen on Unsplash
- 16. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Partitions to the Rescue AWS Glue crawler adds partitions based on file prefixes/ dirs
- 17. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Log S3 Athena Data Catalog Schema Lookup Create table partitions Glue Crawl Partitions with AWS Glue Query data Why? Just schedule the crawler, no need to code! Deals with schema evolution. Crawl data
- 18. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Use Hive-style File Format in S3 Move/ copy: YYYY/MM/DD/HH/file year=YYYY/month=MM/day=DD/hours=HH/file Make Athena reload partitions by: msck repair table Why? Format easy to create on write, easy to move.
- 19. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Log S3 Athena Data Catalog Schema Lookup Add table partition Lambda Creating Partitions with AWS Lambda Query data New File Trigger Why? Add partitions instantly, just AWS Lambda cost.
- 20. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Populate Partitions if paths are known Issue Statements with Amazon Athena: ALTER TABLE mytable ADD PARTITION (year='2015',month='01',day='01') LOCATION 's3://[...]/2015/01/01/' Why? Easy for predictable paths. Can be prepopulated.
- 21. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Columnar Formats
- 22. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Last_Name Label Le Fleming Lisciandro Minghi Jime Age 34 25 45 63 22 Gender Fem Fem Fem Mal Mal Flat File Sample Layout First_Name Tootsie Miriam Blakeley Ernst Brew
- 23. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Columnar Formats Layout (Parquet & ORC) Last_Name Label Le Fleming Lisciandro Minghi Jime MIN: Jime MAX: Minghi Age 34 25 45 63 22 MIN: 22 MAX: 63 Gender Fem Fem Fem Mal Mal MIN: Fem MAX: Mal First_Name Tootsie Miriam Blakeley Ernst Brew MIN: Blakeley MAX: Tootsie
- 24. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Benefit 1: Predicate Pushdown SELECT * FROM ... WHERE Age > 30 Last_Name Label Le Fleming Lisciandro Minghi Jime MIN: Jime MAX: Minghi Age 34 25 45 63 22 MIN: 22 MAX: 63 Gender Fem Fem Fem Mal Mal MIN: Fem MAX: Mal First_Name Tootsie Miriam Blakeley Ernst Brew MIN: Blakeley MAX: Tootsie
- 25. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Benefit 2: Projection Pushdown/ Column Pruning SELECT First_Name FROM ... WHERE Age > 30 Last_Name Label Le Fleming Lisciandro Minghi Jime MIN: Jime MAX: Minghi Age 34 25 45 63 22 MIN: 22 MAX: 63 Gender Fem Fem Fem Mal Mal MIN: Fem MAX: Mal First_Name Tootsie Miriam Blakeley Ernst Brew MIN: Blakeley MAX: Tootsie
- 26. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Benefit 3: Compression & Encoding • RLE (& Bit Packing) for numbers • Dictionary for string repetitions (+RLE) • Delta encoding for increasing numbers • Delta Strings (for string with a identical prefix) • Plain encoding for varied strings https://github.com/apache/parquet-format/blob/master/Encodings.md
- 27. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. More on Dictionary Encoding • Builds list of unique strings, assigns numeric ID to each • If the dictionary size over 1MB (configurable) or number of distinct values too high, will fall back to Plain encoding. • The data itself is later represented as numbers and is further encoded using RLE https://github.com/apache/parquet-format/blob/master/Encodings.md
- 28. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Demo: Parquet/ ORC with Amazon Kinesis Firehose (new!)
- 29. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Analyzing Parquet File • parquet-tools • head – view data in file • meta – get metadata summary • dump -d -n – get detailed metadata down to page level stats included
- 30. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Schema Information Row Count Total Byte Size Size in Bytes Value Count Encoding Download and build [1]. $ java -jar parquet-tools.jar meta <parquetfile> [1] https://github.com/apache/parquet-mr/
- 31. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. parquet-tools dump: Encoding & Statistics total_amount: - DOUBLE SNAPPY DO:0 FPO:4155231 SZ:329324/338501/1.03 [more]... ST:[min: -76.8, max: 1121.3, num_nulls: 0] dropoff_datetime: - BINARY SNAPPY DO:0 FPO:3315979 SZ:839131/5540639/6.60 [more]... ST:[no stats for this column] Use (unix epoch) or partition by timestamp for time series data.
- 32. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Analyzing ORC: orcdumpfile Spin up a single node/ master EMR Cluster and use the hive command: hive --orcfiledump file://<absolutepath>/file.orc […] Column 7: count: 210141 hasNull: false min: - 76.96324157714844 max: 0.0 sum: - 1.5329986951126099E7 Column 8: count: 210141 hasNull: false min: 2018-08-30T00:13:48.573Z max: 2018-08- 30T00:28:49.564Z sum: 5043384 […]
- 33. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Log S3 Athena Data Catalog Schema Lookup Write table partitions Glue ETL with AWS Glue For Frequent Queries Query data Read/ Write
- 34. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Demo: ETL with AWS Glue
- 35. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Example Zeppelin/ AWS Glue Notebook https://gist.github.com/steffeng/ 5b841a99230ba8377f161f5545 3d49d0
- 36. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Photo by Benjamin Davies on Unsplash I applied these simple tricks when storing data for Amazon Athena and you won‘t believe what happened next...
- 37. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Measure. Then optimize. There‘s no silver bullet. Photo by Cesar Carlevarino Aragon on Unsplash
- 38. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Optimize for Cost and Performance 1/2 • Use Athena in the region of your buckets. • Compress your data for less storage & query cost. • Use LIMIT in queries for faster results. • Partition your data based on data access patterns. • Use partitions in your queries. • Add partitions by crawling or S3 triggers.
- 39. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Optimize for Cost and Performance 2/2 • Columnar formats as ORC & parquet reduce scanned data: faster, less cost • Pick format depending on data, access patterns, clients • Inspect/ verify the resulting files • Create aggregates for frequent queries • Shorten turnaround times for Glue job development: • Use a provisioned development endpoint • Use small subset of your data (think KB!)
- 40. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. The AWS Free Tier allows you to get hands on experience with AWS Glue and S3. Try it today!
- 41. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved.© 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. Questions?
