The document discusses X DevAPI, which allows MySQL to be used as both a relational and non-relational (schema-less) database. It provides NoSQL and SQL functionality in a single database using CRUD operations. The presenter worked with X DevAPI at Wix, where they initially used ProxySQL for failover but it did not support X DevAPI. They were able to use InnoDB cluster instead to gain its automatic failover capabilities while taking advantage of X DevAPI.
![List / Drop a
Collection
db.getCollections()
[
<Collection:items_table>,
<Collection:meetup_collection>
]
-- drop collection
db.dropCollection('meetup_collection')
db.getCollections()
[
<Collection:items_table>
]](https://image.slidesharecdn.com/nosqlinsql-lioraltarescu-191128084540/85/Working-with-NoSQL-in-a-SQL-Database-XDevApi-23-320.jpg)
Working with NoSQL in a SQL Database (XDevApi)
- 1. Working with NoSQL in a SQL Database (XDevApi) Lior Altarescu [email protected] linkedin/lioraltarescu github.com/lioraltarescu
- 2. ▪ 7 years a DBA… ▪ Oracle, MySQL, MongoDB, Elasticsearch, Cassandra, and PostgreSQL ▪ Proud data nerd
- 3. TODAY What X DevAPI is Nosql and SQL in a single database CRUD operations Our experience with it
- 4. One big JSON
- 5. X 130M One big JSON
- 6. X 130M One big JSON Team (microservice) #1 Team (microservice) #2
- 8. How developers see data How DBAs see data
- 9. Choose...?
- 10. MySQL
- 12. X DevAPI MySQL C++ Java .Net Node.js Python PHP X Plugin Async CRUD operations
- 13. X DevAPI MySQL C++ Java .Net Node.js Python PHP X Plugin Async CRUD operations session Transparently scale to a multiple server environment
- 15. MySQL It’s a document datastore. Schemaless NoSQL, fully ACID Keeps data integrity Allows SQL & CRUD Max Document size 1G Very secure GTID Replication transaction_isolation
- 16. MySQL ID #1 JSON Collection A A collection of… documents.
- 17. NoSQL and SQL in a single database 02
- 18. Storage Optimizer MySQL connection handling Application MySQL Connector / ODBC Classic MySQL protocol MySQL
- 19. Application MySQL Connector / ODBCX DevAPI X DevAPI X DevAPI SQL result MySQL Storage Optimizer MySQL connection handling X Plugin Classic MySQL protocolX protocol
- 20. Application MySQL Connector / ODBC MySQL Shell Node.js Application Windows Application JavaScript / Python MySQL C / Node.js MySQL connector / Net X DevAPI X DevAPI X DevAPI SQL result MySQL Storage Optimizer MySQL connection handlingX PluginX Plugin Classic MySQL protocolX protocol
- 21. CRUD operations with X DevAPI 03
- 23. List / Drop a Collection db.getCollections() [ <Collection:items_table>, <Collection:meetup_collection> ] -- drop collection db.dropCollection('meetup_collection') db.getCollections() [ <Collection:items_table> ]
- 24. A New Document with SQL: insert into items_table values(‘phone’,21443,’blue’); insert into items_table values(‘phone’,567734,’pink’); with X DevAPI: db.items_table.add({"name":"phone","price":21443,"color":"blue"}). add({"name":"tablet","price":567734,"color":"pink"})
- 25. A New Document with SQL: insert into items_table values(‘phone’,21443,’blue’); insert into items_table values(‘phone’,567734,’pink’); with X DevAPI: db.items_table.add({"name":"phone","price":21443,"color":"blue"}). add({"name":"tablet","price":567734,"color":"pink"}) //OR db.items_table.add({"name":"phone","price":21443,"color":"blue"}) db.items_table.add({"name":"tablet","price":567734,"color":"pink"})
- 26. Find a Document with SQL: select * from items_table where price > 25000; with X DevAPI: db.items_table.find("price>25000") db.items_table.find("price>:param").bind(‘param’,’25000’)
- 27. Modify a Document with SQL: update items_table set price=11111 where name = 'phone’; with X DevAPI: db.items_table.modify("name=phone").set("price","11111") db.items_table.find("name='phone'") { "_id": "00005dc476b00000000000000009", "name": "phone", "color": "blue", "price": 11111 }
- 28. Remove a Document with SQL: delete from items_table where name = 'phone' with X DevAPI: db.items_table.remove("name='phone'")
- 29. A Full Data Transaction var myColl = db.createCollection('dummy_collection'); session.startTransaction(); myColl.add({name: 'Rohit', age: 18, height: 1.76}).execute(); session.setSavepoint('sp1') myColl.add({name: 'Misaki', age: 24, height: 1.65}).execute(); myColl.add({name: 'Leon', age: 39, height: 1.9}).execute(); session.rollbackTo('sp1') session.commit();
- 30. MySQL @Wix 04
- 31. Before X DevAPI
- 33. Switchover
- 34. Does NOT support the X protocol
- 35. Mysql connectors as a replacement to proxySQL ? Connector XdevAPI Failover Load Balancing Java ✓ ✓ ✓ Nodejs ✓ ✓ ✘ Python ✓ ✓ ✘ Net ✓ ✓ ✓ PHP ✓ ✓ ✓ C++ ✓ ✘ ✘
- 36. Play the Waiting Game Solution #1
- 39. Mysql InnoDB cluster Mysql replication Primary election when the current primary failure VS Need to have a script or additional infrastructure for automatic failover Advances AdminAPI for administrative purpose No AdminAPI, regular commands Easy to scale with innodb cluster requires some effort to scale Not mature Solution Mature Solution VS
- 41. X DevAPI allows you to work with MySQL as a document store (both relational and schema-less data). Takeaways
- 42. X DevAPI allows you to work with MySQL as a document store (both relational and schema-less data). Takeaways ProxySQL doesn’t support it, but we got around it with InnoDB cluster.
- 44. Thank You [email protected] linkedin/lioraltarescu github.com/lioraltarescu
